● LED lamps suitable for simple (retrofit) replacement of 200w HID.
● System efficiency up to 93%,
● External power supply, lower temperature rise,Lifespan up to 50000 hours.
● Suitable for indoor application in open luminaires.
● Optional dimming mode, DALI/1-10V/intelligent module remote control.
● Surge resistant common mode and differential mode up to 6KV.
Features
• Up to 130-150lm/w /160lm/w
• High CRI of 82,6-14M application.
• Epistar 2835 1W,LM80,High lumen output.
• LFD brand driver ,ENEC UKCE TUV UL CE certificates,PF>0.95,THD<15.
• Flicker free by camera
• Environmentally friendly, no mercury, No UV, No IR
• IP44,Wterproof,Dustproof, indoor using
• Energy Efficiency Grade: A++
• 5-year-warranty
• Quick Start instant 100% luminous flux
| Product Name | 80W LED High Bay Tube |
| Model number | S4000680 |
| Power | 80W +/-5% |
| Input voltage | 180-265VAC 50/60Hz |
| LED Driver | LFD CE ENEC C-TICK Driver |
| Lumen | 10000-12000LM |
| Lumen efficiency | 130-150LM/W/160LM/W |
| CRI | >80 or >70 |
| Numbers of LED | 216*2pcs2835 |
| Color | 3000k+5000k |
| CCT channel | 3000k/4000k/5000k |
| Power set | 100%-75%-50% |
| Dimming | 0-10v/Smart Module |
| Motion sensor | 4-9m Sensing Range |
| Mounting height | 4-6m |
| PF | >0.95 |
| THD | <15% （full load) |
| Surge Capability (L-N) | 6kv |
| Surge Capability (LN-GND) | 6kv |
| Angle | 110° |
| Housing color | Siverly |
| Material | Aluminum+PC |
| IP | IP44 (Indoor using) |
| Lifespan | >50,000H （tc<85℃） |
| Working Temperature | -25°C~+45°C |
| Operating Humidity | <90% |
| Storage Temperature | -35°C~+80°C |
| Input voltage（AC) | 180Volt 230Volt 240Volt 265Volt |
| Input current at 100% | 0.48A 0.35A 0.36A 0.32A |
| Input power at 100%: | 80W 80W 80W 80W |
| Package Carton | 655*250*210mm |
| Dimension | 600*150*62mm |
| Gross Weight | 7.5kg |
| Net Weight | 6kg (2pcs) |
| Mounting | Suspension/Ceiling installation |
